PJ WX3351N 3,600-lumen desk-edge projector

  • 1,280 x 800 pixels (WXGA)
  • 5,000-hour lamp life (Eco)
  • 40–400-inch projection size
  • Network connectivity

Kết nối và cộng tác dễ dàng, từ lớp học đến các buổi hội họp.

Thu hút sự chú ý khi bạn trình chiếu bài thuyết trình hoặc một đoạn video bất kỳ. Với đặc điểm gọn nhẹ, chất lượng cao, dòng máy chiếu PJ WX3351N phù hợp với các văn phòng và trường học bận rộn.

  1. Trình chiếu màn hình rộng với ít giới hạn hơn
    Dây cáp máy chiếu và tiếng ồn từ quạt làm mát có thể làm ảnh hưởng đến phần thuyết trình của bạn. Thấu hiểu điều này, thiết bị được thiết kế theo hướng điều chỉnh toàn bộ tiếng ồn, nhiệt toả và các dây cáp nối ra khỏi tầm mắt của người nghe.
  2. Máy chiếu kết nối mạng với tuỳ chọn không dây hoặc có dây.
    Kết nối mạng có dây hoặc không dây tiêu chuẩn đem đến tính linh động tối đa. Kết nối Miracast di động hỗ trợ chia sẻ màn hình PC hoặc thiết bị Android của bạn.
  3. Tích hợp âm thanh
    Tận dụng ngay loa gắn trong với âm thanh đạt 10W, để loại bỏ chi phí phát sinh cho loa ngoài.
  4. Truyền thông sáng tạo hơn với trình chiếu 360 độ
    Trình chiếu từ trần cao hoặc ngay trên mặt đất với trình chiếu 360 độ giúp bạn sử dụng thiết bị từ bất kỳ góc độ nào. Tính năng tự động chỉnh sửa góc màn hình sẽ cải thiện ngay những phần hình ảnh bị lệch.

Thiết kế nhỏ gọn, độ sáng cao

Một chiếc máy chiếu nhỏ gọn nhưng đầy cải tiến với các tính năng tăng cường giúp tiết kiệm không gian. Dễ dàng sử dụng nhờ khả năng tự động chỉnh sáng và nhiều phương cách kết nối, bao gồm kết nối từ các thiết bị di động. Trình chiếu video với âm thanh nhờ tận dụng loa ngoài gắn trong máy chiếu - bạn có thể trình chiếu các đoạn phim 3D với độ phóng màn hình lên đến 400 inch. Không còn lo lắng về độ nóng hay tiếng ồn nào có thể làm phiền bạn, tất cả dây cáp và quạt tản nhiệt nay đã được thiết kế đặt vào phần trước của máy chiếu giúp máy được đặt sát cạnh bàn.

Tải về Brochure


Thông số

Loại máy chiếu
Desk-edge
Đi kèm máy
CD-ROM
Includes instruction manual in English, JPEG conversion software, network utility, and projector management utility

Signal cable
RGB cable—3 metres

Power cord
3 metres

Conversion adapter
Yes

Carrier bag
Yes

Remote control
Yes

Battery for remote control
AAA battery x 2
Kích thước vật lý (Rộng x Sâu x Cao) - phần máy chính
297 x 235 x 100 mm
Trọng lượng - thân máy chính
3.1 kg
Hệ thống chiếu
DLP
Độ tương phản
13,000:1
Tỷ lệ khung hình
16:10
Độ sáng
3,600 lumens
Độ phân giải
1,280 x 800 pixels (WXGA)
Tuổi thọ nguồn sáng
3,500h/5,000h (Eco)
Loại đèn chiếu
High-pressure mercury lamp
Công suất đèn chiếu
250 W
Độ dài tiêu cự ống kính
f:13—19.6 mm
Khẩu độ ống kín
F:2.56–3.35
Loại thu-phóng
Manual
Tỷ lệ thu-phóng
1.5x
Phương pháp lấy nét
Automatic
Tái tạo màu sắc
1,073,000,000 colours
Kích thước chiếu
40–400 inches
Khoảng cách chiếu
0.77–12.23 m
Tỷ lệ chiếu
0.89–1.40
Chỉnh sửa góc khung hình
Automatic—vertical
Manual—vertical, horizontal, four corners
Chế độ chiếu
Standard, Rear, Ceiling, Rear ceiling, 360-degree free tilt
Tín hiệu đầu vào
RGB compatible signals (analogue, digital)
WXGA (1,280 x 800), XGA (1,024 x 768), SVGA (800 x 600), VGA (640 x 480)—real display
UXGA (1,600 x 1,200), SXGA (1,280 x 1,024)—compressed representation

Input signals (mono)
NTSC, PAL, SECAM, PAL-M, PAL-60, NTSC 4.43, 50 Hz, 60 Hz, PAL-N

Analogue RGB compatible scanning frequency
15–100 kHz—horizontal
23–85 Hz—vertical
Hỗ trợ 3D
Yes
Hệ thống điều khiển
AMX, Crestron, PJLink
Loa
Internal, 10 W, mono
Các tính năng khác được hỗ trợ
AV mute, Freeze, Resize (magnify), Wall colour correction, Adjuster (front x 2, rear x 1), Multi screen (1 PC to 4 projectors), Automatic brightness control, Closed captioning, Color Universal Design, Presentation timer, Interactive ready (Point blank), Projector management, Miracast, Digital camera connectivity, Simultaneous wired and wireless connectivity, USB firmware updates, Web Image Monitor connectivity, User logo, DLNA, Front exhaust fan, Digital zoom—80 to 100% reduction, High altitude mode—up to 2,500 m
Giao diện - chuẩn

Computer 1 input terminal
Mini D-SUB 15-pin x 1

Computer 2 monitor input/output terminal
Mini D-SUB 15-pin x 1

Video terminal
RCA 1-pin x 1

Audio input terminal
Mini jack x 1

Audio output terminal
Mini jack x 1

PC control terminal
USB Type Mini B x 1

HDMI terminal
HDMI x 1

USB terminal
USB Type A x 1

LAN
RJ-45 x 1 (10Base-T/100Base-TX/1000Base-T compliant)

Wireless LAN
IEEE 802.11a/b/g/n

Communication modes
Ad-hoc, infrastructure, Miracast

Miracast supported devices
Nexus 5 (Android 4.4), Nexus 7 (2013, Android 4.3), Nexus 10 (Android 4.4), Surface 2 (Windows RT 8.1), Surface Pro 3 (Windows 8.1 Pro)

Note: Based on WiFi Certified Miracast standard, but connectivity with all Miracast compatible devices is not guaranteed.

Network authentication
WPA/WPA2-PSK, WPA2-PSK, WPA/WPA2-EAP, WPA2-EAP, open system

Network encryption
WEP, TKIP, CCMP (AES), no encryption

Present direct from USB device (PC-free presentation)
Slide show—still image, animation
Thumbnails—supported
Compatible format for USB memory—JPEG, MPEG2, MPEG4
File extension for USB memory—.jpg, .jpeg, .mpeg, .mpg, .m2ts, .m2t, .mp4, .mov

Digital camera connection support
Pentax
645D, K-50, K-3, K-01, K-5 II, K-5 II S, Q7, Q10, WG-3, WG-3 GPS, WG-4, WG-4 GPS, WG-20, WG-20 GPS, MX-1

Ricoh
G700, GXR GR LENS A12 50mm, GXR GR LENS A12 28mm

Khả năng kết nối mạng
Yes
Khóa Kensington
Yes
Mật khẩu bảo vệ thiết bị
Yes
Các tính năng bảo mật khác

Key lock of device, Security bar

Open SSL acknowledgment
This product includes software developed by the OpenSSL Project to use in the OpenSSL Toolkit (http://www.openssl.org/)
This product includes cryptographic software written by Eric Young ([email protected])
This product includes software written by Tim Hudson ([email protected])

Windows
Network utility software
Windows Vista SP2 or greater—Home Basic, Home Premium, Business, and Ultimate editions
Windows 7 SP 1—Home Premium, Professional, Enterprise, and Ultimate editions
Windows 8 desktop mode—Pro and Enterprise editions
Windows 8.1 desktop mode—Pro and Enterprise editions

JPEG conversion software
Windows Vista SP2 or greater—Home Basic, Home Premium, Business, and Ultimate editions
Windows 7 SP1—Home Premium, Professional, Enterprise, and Ultimate editions
Windows 8—Pro and Enterprise editions
Windows 8.1—Pro and Enterprise editions

Projector management software
Windows Vista SP2 or later—Home Basic, Home Premium, Business, and Ultimate editions
Windows 7 SP1—Home Premium, Professional, Enterprise, and Ultimate editions
Windows Server 2008 SP2
Windows Server 2008 R2 SP1—standard edition
Windows 8—Pro and Enterprise editions
Windows 8.1—Pro and Enterprise editions

Interactive kit software
Windows 7 SP1—Home Premium, Professional, Enterprise, and Ultimate editions
Windows 8 desktop mode—Pro and Enterprise editions
Windows 8.1 desktop mode—Pro and Enterprise editions

Web image monitor
Internet Explorer 8 and above supported

Note: Not compatible with Windows modern UI and Windows RT.
Macintosh
Network utility software—OS X 10.7–10.10, Web Image Monitor—Safari 7
Ngôn ngữ hỗ trợ
Menu languages
Japanese, English, French, German, Italian, Spanish, Portuguese, Russian, Swedish, Turkish, Polish, Norwegian, Czech, Greek, Hungarian, Romanian, Danish, Dutch, Finnish, Thai, Arabic, Traditional Chinese, Indonesian
Tiêu chuẩn
PC free presentation
Network utility software
JPEG conversion software
Projector management utility
Tùy chọn
Interactive kit software
Nguồn điện
100–240 V, 50/60 Hz
Mức độ tiêu thụ điện
316 W—Standard mode
334 W—Maximum power consumption
0.3 W—Standby mode (network off)
1.4 W or less—Standby mode (wired LAN on)
1.8 W or less—Standby mode (wireless LAN on)
Mức công suất âm thanh
38 dB or less—Standard mode
32 dB or less—Eco mode
Các tiêu chuẩn môi trường
Restriction of Hazardous Substances (RoHS)
REACH regulations
ErP (Lot 6, 26)
WEEE
Chuẩn an toàn
EN60950-1 (CE Marking, TUV Mark)
IEC60950-1 (CB attestation)
THA-SAFETY-0001 (power supply)
NZL-SAFETY-0002 (power supply and power cord)
AUS-SAFETY-0003 (power supply and power cord)
Tiêu chuẩn tương thích điện từ (EMC)
EN55022
EN61000-3-2
EN61000-3-3
EN55024 (CE Marking)
EMC (RCM Mark)
HKG (EMC)
Tiêu chuẩn mạng LAN không dây
EN300 328 (CE)
EN301 489-1, EN301 489-17 (CE)
NCC
Wireless RCM mark
ESER
SIRIM
HKG
WPC
NTC
DGPT
Điều kiện hoạt động
Conditions of environment
Temperature 5–35ºC
Relative humidity 30–70%

Storage conditions
Temperature from -10 to 50ºC
Humidity from 15 to 80% relative humidity
Maximum stack 12 cartons

Transportation conditions
Temperature from -10 to 50ºC
Humidity from 15 to 80% relative humidity
Các tính năng hệ điều hành khác
Eco Mode, Carbon meter, Timer On/Off
Projection Calculator

Use this convenient tool to estimate the throw distance for selected Ricoh projectors. It is not intended to provide exact measurements.

Please click the link to visit the Projection Calculator.
