B118W Economical Wax

  • High sensitivity
  • Applicable to a wide range of receiving labels: paper, coated paper, gloss paper

Ribbon Properties
  • Total ribbon thickness: 8 μm
  • Polyester film thickness: 4.5 μm
  • Ink melting point: 65°C
  • Friction coefficient: < 0.2

Download Datasheet     Request Sample Roll

 Application

 B118W Durability

Storage Condition

Usage conditions: 5 to 35°C at 30 to 85% of relative humidity.

Storage conditions: Keep indoors avoiding high temperature, high humidity, direct sunlight.

Storage life: 24 months after production.

Printed Image Durability

 TESTS RESULT

Darkness

 2.1 ± 0.1
Print Quality         ANSI A
Mechanical resistance Level 2 on a scale of 4
Heat resistance
 50oC - 60oC

Certificates

CP65   RoHS   REACH

Halogen Free   135/2004   FDA



Related Products

***The above data represents product averages, allowing for industry accepted variances. These products should be tested in the end-use conditions to ensure that they meet the requirements of the specific application. Specifications may change without notice.
